ENGINE & TRANSMISSION Liquid-cooled, 12 valve, DOHC,
inline 3-cylinder Capacity 660 cc Bore 74.0 mm Stroke 51.1 mm Compression 11.95:1 Max Power EC 81 PS / 80 bhp
(60 kW) @ 10,250 rpm Max Torque EC 47 lbft @ 6,250
rpm Multipoint sequential electronic
fuel injection with electronic throttle control Exhaust
Stainless steel 3 into 1 header system with low single sided
stainless steel silencer Final Drive X-ring chain Clutch Wet, multi-plate, slip
and assist Gearbox 6 speed CHASSIS Frame Tubular steel perimeter
frame Swingarm Twin-sided,
fabricated steel Front Wheel Cast aluminium, 17
x 3.5 in Rear Wheel Cast aluminium, 17
x 5.5 in Front Tire 120/70R17 Rear Tire 180/55R17 Front Suspension Showa
41mm upside down separate function forks (SFF) Rear Suspension Showa
monoshock RSU, with preload adjustment Front Brakes Nissin
two-piston sliding calipers, twin 310mm discs, ABS Rear Brakes Nissin
single-piston sliding caliper, single 255mm disc, ABS Instrument Display and
Functions Multi-function instruments with
colour TFT screen
DIMENSIONS & WEIGHTS Width Handlebars 795 mm Height Without Mirror 1089 mm Seat Height 805 mm Wheelbase 1401 mm Rake 24.6 º Trail 107.3 mm wet weight 189 kg Tank Capacity 14 litres
